Forklifts

Electric Pedestrian Stacker 1500kg

£2,499

£2,200

3 reviews

The DS3 redefines electric stacking for tight spaces. Its dual-chain reinforced mast and iron mesh guard deliver serious durability, while the maintenance-free 24V/80Ah AGM battery (Li-Ion optional) keeps things simple and reliable. The large EP tiller head puts fingertip control at the operator's disposal, with vertical creep speed for precision work and automatic speed reduction at height for added safety. Strong, safe, and straightforward: the DS3 is built to perform.

Lift Height

Get a QuoteRequest Info

Or download datasheet

Estimated delivery within 1-2 weeks

3 year battery warranty

EP Store guaranteed local dealer

Capacity
1500 kg

Lift height
4100 mm

Battery
80 Ah 24 V

Fork dimensions
570 x 1150 mm

Ground clearance
30 mm

Optional
40 Ah Li-Ion

Name	Value
Manufacturer	EP
Model designation	DS3
Drive	Electric
Operator type	Pedestrian
Rated capacity	1500 kg
Load centre distance	600 mm
Load distance, centre of drive axle to fork	802 mm
Wheelbase	1210 mm
Service weight	540 kg
Axle loading, laden front/rear	645/1395 kg
Axle loading, unladen front/rear	395/145 kg
Tyres	Polyurethane
Tyre size, front	Ø190×55 mm
Tyre size, rear	Ø74×88 mm
Additional wheels (castor wheels)	Ø128×50 mm
Wheels, number front/rear (x=drive wheels)	1x 1/2
Tread width, front	597 mm
Tread width, rear	420 mm
Max lift height	3018 mm
Height, mast lowered	2067 mm
Lift	2930 mm
Height, mast extended	3532 mm
Height drawbar in driving position min./max.	760/1140
Height, lowered	91
Overall length	1727 mm
Length to face of forks	577 mm
Overall width	834 mm
Fork dimensions	75/170/1150 mm
Fork carriage width	680 mm
Distance between fork-arms	570
Ground clearance, centre of wheelbase	30 mm
Aisle width for pallets 1000×1200 crossways	2302 Ast
Aisle width for pallets 800 × 1200 crossways	2235 Ast
Turning radius	1470 Wa
Travel speed, laden/unladen	4.0/4.5 km/h
Lift speed, laden/unladen	0.085/0.13 m/s
Lowering speed, laden/unladen	0.105/0.085 m/s
Max. gradeability, laden/unladen	3/10 %
Service brake	Electromagnetic
Drive motor rating S2 60 min	0.75 kW
Lift motor rating at S3 15%	2.2 kW
Battery voltage	24 V
Battery voltage/nominal capacity K5	80/40 Ah
Battery type	Lead Acid/Li-ion
Battery weight	38 kg
Type of drive unit	DC
Steering design	Mechanical
Sound pressure level at the driver's seat	<74 dB(A)
Charger output current	10 A

Sebastian Leitner

Verified buyer

We went with the lithium version and we're very happy with it. Short charging times and no drop in performance during daily use. The stacker is quiet, precise to control, and ideal for our regular but not overly heavy tasks.

Thomas Berger

Verified buyer

We have limited space, so the compact design was a deciding factor. The DS3 feels solid and works reliably. I find the integrated charger especially practical: just plug it into the socket and you're good to go.

Florian Winkler

Verified buyer

No unnecessary frills, just exactly what you need. The DS3 is easy to maintain, simple to charge, and has been running without any issues so far. A solid solution for internal transport operations.

Explore the DS3

The DS3 thrives where space is tight and efficiency matters. Purpose-built for warehouses, retail floors, and small distribution centres, it handles stacking, loading, and transport with ease. A compact footprint and tight turning radius let it navigate narrow aisles and crowded production areas without breaking stride. From racking pallets to shifting stock in back rooms, the DS3 delivers quiet, energy-efficient performance wherever the job demands it.

Compact and manoeuvrable

Reinforced mast

Maintenance-free power

Safe and ergonomic

Our dedicated sales and support network for the DS3

With the support of EP Equipment distributors spread across the UK, you are guaranteed to receive fast assistance, personalised advice and original parts for your DS3.

More and more companies are replacing their old equipment with 100% electric solutions like the DS3, appreciated for their compactness, quiet operation and reduced operating costs.

Choosing the DS3 means choosing a sustainable alternative, without compromising on power, versatility and autonomy.

Thanks to our network of partners in the UK, you benefit from:

Fast delivery of trucks like the DS3
Qualified and responsive technical support
Constant availability of original spare parts

Ready to connect with your local dealer?

Get a QuoteRequest Info

FAQs

Common questions people ask about the DS3.

What battery and charger system does the DS3 use?
The standard model comes with a 24 V/80 Ah maintenance-free AGM battery and an integrated 10 A charger. A 24 V/40 Ah Li-ion battery with a 15 A charger is available as an option for increased efficiency and reduced charging time.
Is the DS3 suitable for narrow aisles?
Yes. With an aisle width requirement of just 2235 mm (for 800×1200 mm pallets lengthways), the DS3 is ideal for compact warehouse layouts where manoeuvrability is essential.
What safety and comfort features does the DS3 include?
The DS3 features speed reduction when elevated, an ergonomic EP tiller with fingertip controls, vertical creep speed for precise operation, and an iron mesh mast guard for added operator protection.
